--- title: "Deploying and configuring Datadog with CloudFormation" description: "Learn to use Datadog with AWS CloudFormation to increase observability by defining infrastructure as code." author: "David M. Lentz" date: 2019-01-14 tags: ["infrastructure monitoring", "aws", "aws cloudformation", "cloudformation", "monitoring as code"] blog_type_id: the-monitor locale: en --- In this post, we will show you how you can use AWS CloudFormation to automatically deploy infrastructure that is preconfigured to send metrics and logs to Datadog. To demonstrate how this works, we will use a sample CloudFormation template that creates an EC2 instance running Apache web server, then installs the Datadog Agent, configures it with your API key, and enables Datadog's integration with Apache. If you're not already using Datadog, you can still follow along with the steps in this post by signing up for a . ## What is AWS CloudFormation? CloudFormation is a configuration management service from AWS that allows you to create and update infrastructure programmatically. A CloudFormation **template** is a JSON or YAML file you create to describe your desired infrastructure. A template defines the properties of each resource (such as an EC2's instance type), and the configuration CloudFormation will apply to attain the infrastructure's desired state. Each template defines a **stack**—a collection of logically related AWS resources, such as EC2 instances, VPCs, Elastic Load Balancers, and IAM roles. The components of the stack are defined in the template's `Resources` section. For example, to create an EC2 instance from a preconfigured Amazon Machine Image (AMI) using CloudFormation, your template would contain YAML like this: ```yaml Resources: MyEC2Instance: Type: "AWS::EC2::Instance" Properties: InstanceType: t2.small ImageId: ami-011b6930a81cd6aaf ``` A CloudFormation template is **infrastructure as code**. Rather than code that's imperative—defining a specific path in creating the infrastructure—the template uses declarative language to define a new stack or revisions to an existing stack. When you execute the template (using the CloudFormation console, SDK, or CLI), CloudFormation compares the state of the infrastructure to the desired state you've declared, then determines and executes the steps necessary to attain the desired state. Like any code, the templates that describe your infrastructure can be versioned and reused. Each time you execute a CloudFormation template, you create a stack identical to any others based on that template. This allows you to run identical environments for different purposes (such as QA and development), and supports devops practices like [blue/green deployments](https://aws.amazon.com/blogs/devops/bluegreen-infrastructure-application-deployment-blog/). CloudFormation is similar to other configuration management software, like [Chef](https://www.datadoghq.com/blog/deploying-datadog-with-chef-roles.md) and [Ansible](https://www.datadoghq.com/blog/deploy-datadog-ansible-reporting.md), which support the same goal of managing infrastructure as code. ## CloudFormation + Datadog CloudFormation can deploy infrastructure that's readily observable. Including the configuration and deployment of the Datadog Agent in your CloudFormation template gives you visibility into your infrastructure as soon as it comes online. The Datadog Agent is a lightweight, open source application that collects and forwards metrics, logs, and distributed request traces to your Datadog account. As soon as the Agent is running on your EC2 instances, you'll be able to see host-level metrics beyond what's reported by [Amazon CloudWatch](https://aws.amazon.com/cloudwatch/), and you'll be able to visualize your logs and APM data in Datadog. ![Custom Datadog dashboard shows metrics and logs from an EC2 instance.](https://web-assets.dd-static.net/42588/1776299014-deploying-datadog-with-cloudformation-custom_timeboard4.png) ## Templating the Datadog integration In this section, we'll look at the anatomy of our [demonstration template](https://gist.githubusercontent.com/davidmlentz/8e90571c63fda3e45b26dfb3ce5c7d2b/raw/47b72a9df9b130be9d3ef56b3ec3adda18dd549b/datadog_cloudformation.yaml) and highlight some of the code that defines key characteristics of the stack it creates. Our template creates two AWS resources and a Datadog resource. (See our [CloudFormation Registry blog post](https://www.datadoghq.com/blog/monitoring-as-code-with-datadog-and-cloudformation.md) for information about deploying Datadog resources via CloudFormation.) The AWS resources are an EC2 instance (which the template identifies as `MyWebServerInstance`, since it will include the Apache server) and an associated security group (identified as `MySecurityGroup`), which allows traffic on the instance’s port 80. The Datadog resource (`DatadogMonitorResource`) is a monitor that will alert you if your EC2 instance becomes unavailable. This template accepts two parameters: 1. Your Datadog API key, which is used by the Agent to automatically send metrics and logs to your Datadog account 1. Your application key, which—along with your API key—is used to authenticate your request to create the Datadog monitor The template is broken down into sections, each of which fills a purpose in creating the stack: - **Parameters.** This section defines values to be provided when the template is executed. CloudFormation uses the parameter values passed by the user (or the parameters' default values) to configure stack properties such as your Datadog API key or the name of your SSH key pair. - **Resources.** This is the only required section in a CloudFormation template. It defines the AWS resources to be created (or updated) by the template. - **Outputs.** This section defines the values to be returned when the template is executed. The key name of each output is defined in the template, and its value is returned when template execution is complete. The other sections that comprise a CloudFormation template are its **description**, **transform**, **metadata**, **conditions**, and **mappings**. For information about these sections, see the [CloudFormation user guide](https://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/template-anatomy.html). ### Parameters section: API key and application key The first section of our template defines its parameters. A `Parameters` section is optional in a CloudFormation template, but by defining template parameters, you can require the user to provide values that will be plugged into the template to configure the requested resources. The demo template defines the `APIKey` and `APPKey` parameters. *datadog_cloudformation.yaml* ```yaml Parameters: APIKey: Description: "The API key for your Datadog account" Type: String APPKey: Description: "An application key from your Datadog account" Type: String ``` You'll input your Datadog API key and application key when you execute the template. CloudFormation uses the API key to configure the Agent to submit data to your Datadog account, and then uses both keys to authenticate the call to create the Datadog monitor resource. ### Resources section: Metadata You can use the `AWS::CloudFormation::Init` metadata key to specify characteristics of an EC2 instance, such as users and groups that should be present, services that should be running, and more. This gives you great flexibility in automating the configuration of your instances; see the [AWS documentation](https://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/aws-resource-init.html) to learn more about what you can do with `AWS::CloudFormation::Init`. In our demonstration template, `AWS::CloudFormation::Init` organizes instance configuration details into three groups called **configsets**. Our configsets organize the instance's configuration into three logical areas: packages to be installed, configuration details for Apache and the Agent, and instructions to restart the services to apply the updated configurations. The YAML snippet below shows the definitions of the configsets: *datadog_cloudformation.yaml* ```yaml AWS::CloudFormation::Init: configSets: # List the configSets and the config keys they contain: Install: - "installHttpd" - "installDatadogAgent" Configure: - "configureModStatus" - "enableLogs" - "configureLogs" Restart: - "restart" ``` Each configset contains only a list of configuration items, called **config keys**, which specify the configuration details. In the following sections, we'll look at the YAML in each config key that defines the commands that will run and packages that will be installed on the instance. When the template is executed, CloudFormation triggers a script that reads all the config keys and determines how to achieve the desired configuration. We'll look more closely at this process in the UserData section. #### Configset: Install The first config key in this set, `installHttpd`, contains directives to ensure that Apache is installed and running on the instance: *datadog_cloudformation.yaml* ```yaml installHttpd: packages: yum: httpd: [] services: sysvinit: httpd: enabled: true ensureRunning: true ``` The next config key, `installDatadogAgent`, downloads and installs the Agent using the one-step installation script, plugging in the API key that the user has provided as a parameter: *datadog_cloudformation.yaml* ```yaml installDatadogAgent: commands: 01_download_and_install: env: DD_API_KEY: !Sub "${APIKey}" command: "bash -c \"$(curl -L https://raw.githubusercontent.com/DataDog/datadog-agent/master/cmd/agent/install_script.sh)\"" ``` #### Configset: Configure The elements in the `Configure` configset modify Apache's configuration, then update the configuration of the Agent so it can collect and tag metrics and logs from Apache. The first key in this configset, `configureModStatus`, enables Apache's `mod_status` module. This makes [the Apache status page](https://www.datadoghq.com/blog/collect-apache-performance-metrics.md#apaches-status-module) available for the Agent to use as a source for metric data. *datadog_cloudformation.yaml* ```yaml configureModStatus: commands: 01_add_config: command: !Sub | cat < /etc/httpd/conf.d/server-status.conf # Enable the /server-status page ExtendedStatus on SetHandler server-status Allow from localhost EOT ``` For more information about the `mod_status` module, see the [Apache documentation](https://httpd.apache.org/docs/2.4/mod/mod_status.html). The next config key, `enableLogs`, updates the **datadog.yaml** file and enables the Agent to collect logs. Then it sets an [access control list (ACL)](https://access.redhat.com/documentation/en-us/red_hat_enterprise_linux/7/html/system_administrators_guide/ch-access_control_lists) on the directory where Apache stores logs, so the Agent can access them. It also adds this ACL instruction to the host's `logrotate` configuration so it's automatically reapplied when Apache logs are rotated. *datadog_cloudformation.yaml* ```yaml enableLogs: commands: 01_update_datadog_yaml: cwd: "/etc/datadog-agent/" command: "sed -i 's/^# logs_enabled: false$/logs_enabled: true/' datadog.yaml" 02_fix_logfile_permissions: command: "setfacl -m u:dd-agent:rx /var/log/httpd" 03_sed_logrorate: cwd: /etc/logrotate.d command: "sed -i 's#/bin/systemctl reload httpd.service > /dev/null 2>/dev/null || true#/bin/systemctl reload httpd.service > /dev/null 2>/dev/null || true; setfacl -m u:dd-agent:rx /var/log/httpd#' httpd" ``` The `configureLogs` key updates the Agent's Apache configuration file so it can collect and tag access and error logs, and collect metrics from Apache's status page. *datadog_cloudformation.yaml* ```yaml configureLogs: commands: 01_create_apache_conf_yaml: cwd: "/etc/datadog-agent/conf.d/apache.d/" command: cp conf.yaml.example conf.yaml 02_update_apache_conf_yaml: cwd: "/etc/datadog-agent/conf.d/apache.d/" command: !Sub | cat <> conf.yaml logs: - type: file path: /var/log/httpd/access_log source: apache sourcecategory: http_web_access service: myservice tags: - env:qa - type: file path: /var/log/httpd/error_log source: apache sourcecategory: http_web_access service: myservice tags: - env:qa EOT ``` The first command in this key copies the sample configuration file, [**conf.yaml.example**](https://github.com/DataDog/integrations-core/blob/master/apache/datadog_checks/apache/data/conf.yaml.example) to **conf.yaml** so the Agent can recognize and use it. The second command adds a `logs` element to that file, which specifies the path to Apache's log files, and tells the Agent to tag the logs with `service: myservice` and `env: qa`. You can customize these tags to suit your needs. The `source` tag tells Datadog to route the incoming logs through an Apache-specific [processing pipeline](https://docs.datadoghq.com/logs/processing/pipelines.md), and the `sourcecategory` tag can help you aggregate related logs across hosts and services. For more information on using these tags, see our [tagging documentation](https://docs.datadoghq.com/tagging.md). #### Configset: Restart The command in the `restart` key restarts Apache and the Agent to apply all configuration changes. *datadog_cloudformation.yaml* ```yaml restart: commands: 01_restart: command: "systemctl restart httpd.service; systemctl stop datadog-agent.service; systemctl start datadog-agent.service" ``` ### Resources section: Instance properties The `Properties` section of the template defines the characteristics of the `MyWebServerInstance` being created. #### UserData When the instance comes up, it executes the bash script in the `UserData` section of the template. First, this script instructs the instance to update its `aws-cfn-bootstrap` package: *datadog_cloudformation.yaml* ```yaml yum update -y aws-cfn-bootstrap ``` This package contains helper scripts CloudFormation will use to configure the instance. One of these helper scripts is `cfn-init`. CloudFormation calls `cfn-init` and references the three configsets—`Install`, `Configure`, and `Restart`—defined in the [`AWS::CloudFormation::Init` section](#resources-section-metadata) of the template: *datadog_cloudformation.yaml* ```yaml /opt/aws/bin/cfn-init -v --stack ${AWS::StackName} --resource MyWebServerInstance --configsets Install,Configure,Restart --region ${AWS::Region} ``` #### InstanceType The `InstanceType` value designates the class and size of the EC2 instance. *datadog_cloudformation.yaml* ```yaml InstanceType: t2.nano ``` In this demo template, `InstanceType` is hardcoded as `t2.nano`. For a more flexible template, you could include `InstanceType` as a parameter, allowing the user to select an `InstanceType` value when executing the template. The `ImageId` element specifies the AMI that CloudFormation will use as the basis for the instance to be created. *datadog_cloudformation.yaml* ```yaml ImageId: ami-011b6930a81cd6aaf ``` This demo template specifies an Amazon Linux 2 AMI for the us-west-1 region. You can change your copy of the template to specify an image from a different region. (To find the `ImageId` for an AMI in a different region, visit the EC2 section of the AWS console and click **Launch Instance**.) A production-ready CloudFormation template will include a mapping of AMIs available in each region, and will automatically select the one appropriate for the region where the template is executed. This ensures that the template is reusable in any region. For guidance on creating a template that programmatically determines the correct AMI ID for a given region and instance type, see [this document from AWS](https://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/walkthrough-custom-resources-lambda-lookup-amiids.html). ### Resources section: Security group An AWS security group acts as a virtual firewall, governing the flow of traffic to and from your infrastructure. All EC2 instances have at least one associated security group. If you create an EC2 instance without specifying a security group, the [default security group](https://docs.aws.amazon.com/AWSEC2/latest/UserGuide/using-network-security.html#default-security-group) is applied. But because the default security group doesn't allow traffic to or from port 80, the demo template creates a custom security group that exposes port 80 externally. *datadog_cloudformation.yaml* ```yaml MySecurityGroup: Type: "AWS::EC2::SecurityGroup" Properties: GroupDescription: "Allow web traffic" SecurityGroupIngress: - CidrIp: 0.0.0.0/0 FromPort: '80' IpProtocol: tcp ToPort: '80' ``` ### Outputs section After creating the EC2 instance, CloudFormation returns values for the output variables defined in the template. *datadog_cloudformation.yaml* ```yaml Outputs: URL: Description: "The URL of this instance's website" Value: !Sub "http://${MyWebServerInstance.PublicIp}" InstanceDashboard: Description: "Link to this instances's Datadog dashboard" Value: !Sub "https://app.datadoghq.com/dash/host_name/${MyWebServerInstance}" ``` Below, we'll show how you can use the `URL` and `InstanceDashboard` output values to begin monitoring your stack in Datadog. ## Creating your integrated stack As outlined above, the demo template defines a small stack, including an EC2 host running an Apache server that's configured to send metrics and logs to your Datadog account. In this section, we'll walk you through executing the template to create the stack, then viewing your instance's metrics and logs in Datadog. ### Execute the template Download the [demo template](https://gist.githubusercontent.com/davidmlentz/8e90571c63fda3e45b26dfb3ce5c7d2b/raw/47b72a9df9b130be9d3ef56b3ec3adda18dd549b/datadog_cloudformation.yaml) to your local storage, then navigate to the CloudFormation page in the AWS console. (Make sure you're in the us-west-1 (**US West (N. California)**) region for this demo, since the template [specifies an AMI from that region](#resources-section-instance-properties).) Click **Create Stack**. Under **Choose a template**, click **Choose File** and navigate to your local copy of the template. Click **Next**. In the next screen, enter a name for your stack in the **Stack name** field. Next, enter your Datadog API key in the **APIKey** field and an application key from your Datadog account in the **APPKey** field. (To find these keys, look in the **API Keys** and **Application Keys** sections on [this page](https://app.datadoghq.com/account/settings#api).) Click **Next**. In the screen that appears next, you can optionally tag your stack using the **Key** and **Value** fields. Any tags you add here will be applied to all the resources in the stack (in this case, the EC2 instance and the security group), and to the CloudFormation stack itself. Datadog ingests these tags automatically so you can filter and aggregate all your monitoring data on the fly. To add more than one tag, click the plus sign on the right. Leave the other fields on this page empty. Scroll down and click **Next**. Review the stack information you've provided, then click **Create**. Next you'll see a table that contains a list of your stacks. In the **Status** column, your new stack's status will initially appear as **CREATE_IN_PROGRESS**. ![The AWS console shows your stack creation in progress.](https://web-assets.dd-static.net/42588/1776299018-deploying-datadog-with-cloudformation-create_in_progress1.png) After a few minutes, it should change to **CREATE_COMPLETE**, and you're ready to proceed. ### View your host's metrics and logs When your stack creation is complete, click to highlight your stack's row in the table, then click the **Outputs** tab. ![The AWS console shows your stack creation is complete.](https://web-assets.dd-static.net/42588/1776299022-deploying-datadog-with-cloudformation-create_complete2.png) Click the value in the **InstanceDashboard** row to navigate to the host dashboard in your Datadog account. ![The new EC2 instance's dashboard is visible in your Datadog account.](https://web-assets.dd-static.net/42588/1776299027-deploying-datadog-with-cloudformation-host_dash2.png) The EC2 host you created in your new stack is now sending metrics to Datadog. Back in your AWS console, click the **URL** value in the **Outputs** tab to load the instance's website in your browser. Reload the page several times to generate traffic to your web server. Return to the host dashboard and note the **Apache - Hits rate** graph. The traffic you just generated in your browser should show as a spike, as in the screenshot below. You may see other requests at regular intervals on the graph, due to the Agent making regular calls to the Apache status page. ![apache_hits_rate2a](https://web-assets.dd-static.net/42588/1776299031-deploying-datadog-with-cloudformation-apache_hits_rate2a.png) You can easily pivot from viewing your host's metrics on the graph to browsing related logs. Click a point on the **Apache - Hits rate** graph, then click the **View related logs** option. ![apache_hits_rate2b](https://web-assets.dd-static.net/42588/1776299036-deploying-datadog-with-cloudformation-apache_hits_rate2b.png) The Log Explorer will show your host's time-correlated Apache logs, as shown in the screenshot below. ![This Log Explorer view shows logs that share the same Source value as the metrics above.](https://web-assets.dd-static.net/42588/1776299040-deploying-datadog-with-cloudformation-log_explorer3.png) ## Start deploying Datadog with CloudFormation In this post we've shown you how to deploy an EC2 instance running Apache server, and how to install and configure the Datadog Agent to monitor Apache and the host itself. To go further with CloudFormation and Datadog, you can build on this template to configure any of Datadog's 1,000 other integrations. If you're not already using Datadog, you can get started with a .
